Intel Core i7-14700F 2.1 GHz 20-Core Processor

Sale Price: $344.98 Original Price: $415.00

Save $68.00 ( 17% )


FREE SHIPPING
EASY HASSLE-FREE RETURNS

Shop All Desktop Processors
Visit The Intel Store

  • 20 cores (8 P-cores + 12 E-cores) and 28 threads

  • Performance hybrid architecture integrates two core microarchitectures, prioritizing and distributing workloads to optimize performance

  • Up to 5.4 GHz unlocked. 33MB Cache

  • Compatible with Intel 600-series (with potential BIOS update) and 700-series chipset-based motherboards

  • PCIe 5.0 & 4.0 support. DDR4 and DDR5 Memory support. RM1 thermal solution included. Discrete graphics required.

Save $68.00 ( 17% )


FREE SHIPPING
EASY HASSLE-FREE RETURNS

Shop All Desktop Processors
Visit The Intel Store

  • 20 cores (8 P-cores + 12 E-cores) and 28 threads

  • Performance hybrid architecture integrates two core microarchitectures, prioritizing and distributing workloads to optimize performance

  • Up to 5.4 GHz unlocked. 33MB Cache

  • Compatible with Intel 600-series (with potential BIOS update) and 700-series chipset-based motherboards

  • PCIe 5.0 & 4.0 support. DDR4 and DDR5 Memory support. RM1 thermal solution included. Discrete graphics required.

Introducing The Intel Core i7 - 14700F Desktop Processor

Power up your productivity, gaming, and content creation with the Intel Core i7-14700F 2.1 GHz 20-Core LGA 1700 Processor. Built with the Intel 7 process, this 14th generation desktop processor delivers improved power efficiency with a total of 20 cores while fitting the LGA 1700 socket. Featuring an optimized Hybrid Core Architecture, the Core i7-14700F powers demanding applications and games with eight 2.1 GHz Performance-cores, while the 12 low-voltage Efficient-cores handle background tasks for smooth multitasking. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time. With 33MB of cache and a 5.4 GHz Turbo Boost Max 3.0 frequency, this processor is made to handle intense workloads. The Core i7-14700F also supports PCI Express 5.0 and up to 192GB of dual-channel DDR5 ECC memory at 5600 MHz. The Core i7-14700F does not include integrated graphics, meaning that users will need to purchase a separate dedicated graphics card. A Laminar RM1 cooler is included.

Hybrid Core Design

Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks such as streaming video, playing music, and encoding media are handled by the processor's Efficient-cores.

Intel Thread Director

The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 28 threads are assigned to the right core at the right time.

PCIe 4.0 & 5.0

This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.

Gaussian & Neural Accelerator 3.0

Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.

Intel Deep Learning Boost

Accelerates AI inference to improve performance for deep learning workloads.

Here are the features of the product.

  • 20 Cores & 28 Threads
  • 2.1 GHz Base P-Core Clock Speed
  • 5.4 GHz Maximum Turbo Boost Frequency
  • LGA 1700 Socket
  • 33MB Cache Memory
  • Dual-Channel DDR5-5600 ECC Memory
  • Hybrid Core Architecture
  • Includes Laminar RM1 Cooler
  • 14th Generation (Raptor Lake-S Refresh)

These are the technical specifications.

Key Specs
CPU Model
Intel Core i7-14700F (14th Gen)
CPU Socket
LGA 1700
Unlocked
No
Number of Cores
20 (8 x P-Cores + 12 x E-Cores)
Base Clock Speed
P-Core: 2.1 GHz
E-Core: 1.5 GHz
Maximum Boost Speed
P-Core Turbo 3.0: 5.4 GHz
P-Core Turbo: 5.3 GHz
E-Core Turbo: 4.2 GHz
Thermal Design Power (TDP, Max)
65 W
Included Thermal Solution
Laminar RM1
General
CPU Model
Intel Core i7-14700F (14th Gen)
CPU Socket
LGA 1700
Manufacturing Process
10 nm
Maximum CPU Configuration
1S
Maximum Number of PCIe Lanes
20 (Revision 5.0)
Unlocked
No
Performance
Number of Cores
20 (8 x P-Cores + 12 x E-Cores)
Number of Threads
28
Base Clock Speed
P-Core: 2.1 GHz
E-Core: 1.5 GHz
Maximum Boost Speed
P-Core Turbo 3.0: 5.4 GHz
P-Core Turbo: 5.3 GHz
E-Core Turbo: 4.2 GHz
Dedicated AI Cores
No
L3 Cache
33 MB
Memory Support
Maximum Capacity
192 GB
Memory Support
DDR5 Up to 5600 MT/s
DDR4 Up to 3200 MT/s
ECC Memory
Yes
Channel Architecture
Dual Channel
Maximum Memory Bandwidth
89.6 GB/s
Optane Memory Support
No
Power
Thermal Design Power (TDP, Max)
65 W
Included Thermal Solution
Laminar RM1
Maximum Temperature
212°F / 100°C
Thermal Monitoring Technologies
Yes
Technology
AES Support
Yes
Extension
AVX 2.0, SSE 4.1/4.2
Instruction Set
64-Bit
Virtualization
Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT)
DMI
DMI4 (16 GT/s)
vPro Support
Yes
Performance Technologies
Deep Learning Boost, Gaussian and Neural Accelerator 3.0, Thermal Velocity Boost, Turbo Boost Max 3.0
Security Technologies
Control-Flow Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS Guard, Secure Key
Packaging Info
Package Weight
1.045 lb
Box Dimensions (LxWxH)
5.1 x 4.6 x 2"
