Gigabyte X870 AORUS ELITE WIFI7 AM5 ATX Motherboard

$268.98 $329.00

Save: $60.00 ( 18% OFF )
For a Limited Time Only

Shop The Gigabyte Store

Free Shipping On All Orders
Free Hassle-Free Returns

Shop All Motherboards

  • AMD Socket AM5: Supports AMD Ryzen 9000 / Ryzen 8000 / Ryzen 7000 Series Processors

  • DDR5 Compatible: 4 x DIMMs with AMD EXPO Support

  • Power Design: 16 plus2 plus2

  • Thermals: VRM and M.2 Thermal Guard

  • Connectivity: PCIe 5.0, 4x M.2 Slots, Dual USB4, Front and Rear USB-C, Sensor Panel Link

Save: $60.00 ( 18% OFF )
For a Limited Time Only

Shop The Gigabyte Store

Free Shipping On All Orders
Free Hassle-Free Returns

Shop All Motherboards

  • AMD Socket AM5: Supports AMD Ryzen 9000 / Ryzen 8000 / Ryzen 7000 Series Processors

  • DDR5 Compatible: 4 x DIMMs with AMD EXPO Support

  • Power Design: 16 plus2 plus2

  • Thermals: VRM and M.2 Thermal Guard

  • Connectivity: PCIe 5.0, 4x M.2 Slots, Dual USB4, Front and Rear USB-C, Sensor Panel Link

Gigabyte X870E AORUS ELITE WIFI7 AM5 ATX Motherboard

Product description goes here...

$268.98

Extra Info

  • Free Shipping
  • 30-Day Returns
  • Made in USA

Center your gaming build around the Gigabyte X870E AORUS ELITE WIFI7 AM5 ATX Motherboard. This motherboard supports AMD 7000, 8000, and 9000 series processors, which utilize the AM5 socket. With four DDR5 slots, one PCIe 5.0 x16 slot with PCIe UD Slot X, one PCIe 4.0 x4 slot, one PCIe 3.0 x4 slot, four M.2 2280 slots, and four SATA slots, you'll be able to build a powerful gaming rig with this motherboard. With EZ-Latch Plus and Click, installing a graphics card and M.2 SSDs with heat sinks is user-friendly and doesn't require tools. For online connectivity, the motherboard provides fast 2.5GbE LAN and Wi-Fi 7. Install Windows 11 (64-bit) to take full advantage of all the features of this motherboard.

AORUS AI SNATCH

Unleash optimal performance with one-click activation. With just a single click, unleash the full potential of DDR5 memory, instantly boosting performance for gaming and creative content. Get enhanced computing power, fast AI performance, EZ to Peak, safe overclocking, and less power usage. Zenith of the Memory

Shielded Memory Routing

Advanced shielding inside the PCB keeps your memory signals clean and interference-free

Daisy-Chained Routing

Innovative design removes signal bottlenecks, allowing for fast memory speeds and an optimal gaming setup

6-Layer Server-Grade PCB

Top-of-the-line server-grade PCB material minimizes signal loss, providing fast DDR5 data transmission.

Digital Twin VRM Design

This motherboard delivers consistent, high-powered performance to elevate your overclocking to the next level. 16 VCORE phases unlock the full power of your multi-core CPU while 2 SOC phases are optimized for integrated GPU performance and memory management within the CPU. 2 MISC phases provide reliable power to your CPU-connected PCIe lanes for uninterrupted performance.

Wi-Fi 7

Wi-Fi 7 introduces support for expansive 320/160 MHz channels, dramatically increasing bandwidth for fast data transfer speeds. Leveraging 4K-QAM technology, Wi-Fi 7 elevates data throughput, enabling fast file transfers and buffer-free streaming. Wi-Fi 7's MLO (Multi-Link Operation) technology allows strategic bandwidth allocation - dedicating 2.4 GHz for streaming and 5/6 GHz for gaming, resulting in an interruption-free network experience. With its deterministic low latency, Wi-Fi 7 minimizes delays, making it the ideal choice for time-sensitive applications, such as video conferencing and competitive online gaming.

2.5GbE LAN

Supercharge your online gaming with the 2.5GbE RJ45 LAN jack. With fast speeds, minimal lag, and optimal performance, you'll be able to elevate your gaming rig for online competition.

EZ Debug Zone

Centralized debug LEDs and control buttons provide a handy and organized troubleshooting process when building a new computer.

EZ-Latch Designs

PCIe EZ-Latch Plus Easy ejection with a single slick for graphics cards

M.2 EZ-Latch Click

Tool-less installation for M.2 heat sink

M.2 EZ-Latch Plus

Tool-less installation for M.2 SSDs

Q-FLASH

Q-FLASH Auto Scan

When using USB flash drive during Q-Flash, the BIOS file will be auto scanned instead of searching manually

Q-FLASH Plus

Upgrade your BIOS without the need to install the CPU, RAM, or GPU first

Sensor Panel Link

The built-in video port streamlines the Sensor Panel setup without management concerns.

Ultra Durable Design

PCIe UD Slot X M.2 UD Slot PG5 UD Power Connector Ultra Durable PCIe Armor Gigabyte Control Center RGB Fusion Customize the RGB lighting with precise control over individual LEDs with Gigabyte Control Center.

Here are the features of the product.

  • ATX Form Factor
  • AMD X870E Chipset
  • AM5 Socket
  • 4 x Dual-Channel DDR5 Slots
  • 1 x PCIe 5.0 x16 with PCIe UD Slot X
  • 1 x PCIe 4.0 x4 | 1 x PCIe 3.0 x4
  • 4 x SATA | 4 x M.2 2280
  • 2.5GbE LAN | Wi-Fi 7 | Bluetooth 5.4
  • EZ-Latch Plug, Plus, & Click
  • Supports Windows 11 (64-Bit)

These are the technical specifications.

Best Seller Ranking #25 in AMD Motherboards
Brand GIGABYTE
Model X870 AORUS ELITE WIFI7
Model
CPU Socket Type AM5
CPU Type Ryzen 7000 Series / Ryzen 8000 Series / Ryzen 9000 Series
Supported CPU
Chipset AMD X870
Chipsets
Number of Memory Slots 4x288pin (DDR5)
Memory Standard DDR5 5200
Maximum Memory Supported 256GB
Channel Supported Dual Channel
ECC Supported Non-ECC
Buffer Supported Un-buffered
Memory Feature Support for DDR5 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
Memory
PCI Express 5.0 x16 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x16 mode
* The M2B_CPU and M2C_CPU connectors share bandwidth with the PCIEX16 slot.

When the M2B_CPU or M2C_CPU connector is populated, the PCIEX16 slot operates at up to x8 mode.
AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
(The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.)
PCI Express x4 Chipset:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
* The PCIEX4 slot shares bandwidth with the M2D_SB connector. The PCIEX4 slot becomes unavailable when a device is installed in the M2D_SB connector.

- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x2 (PCIEX2)
Expansion Slots
Serial ATA (SATA) 4 x SATA 6Gb/s
M.2 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs

2 x M.2 connectors (M2B_CPU, M2C_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
* The M2B_CPU and M2C_CPU connectors become unavailable when an AMD Ryzen 8000 Series-Phoenix 1/Phoenix 2 processor is used.

1 x M.2 connector (M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs
SATA RAID 0/1/10
Storage Devices
Audio Chipset Realtek ALC1220
Audio Channels 7.1 Channels
Onboard Audio
Max LAN Speed 2.5Gbps
Wireless LAN Wi-Fi 802.11 be
Bluetooth BLUETOOTH 5.4
Onboard LAN
Back I/O Ports 1 x Q-Flash Plus button
1 x HDMI port
2 x antenna connectors (2T2R)
2 x USB4 USB Type-C ports (DisplayPort)
2 x USB 3.2 Gen 2 Type-A ports (red)
4 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
1 x optical S/PDIF Out connector
2 x audio jacks
Rear Panel Ports
Onboard USB 1 x USB Type-C header, with USB 3.2 Gen 2x2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
Other Connectors 1 x CPU fan header
1 x CPU fan/water cooling pump header
4 x system fan headers
2 x system fan/water cooling pump headers
3 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
4 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x noise detection header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
1 x HDMI port
1 x power button
1 x reset button
2 x temperature sensor headers
1 x reset jumper
1 x Clear CMOS jumper
Internal I/O Connectors
Form Factor ATX
Dimensions (W x L) 12.0" x 9.6"
Power Pin 1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
Physical Spec
BIOS Feature 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Software Norton Internet Security (OEM version)
LAN bandwidth management software
Windows 11 Supported
Software Feature
Features Support for GIGABYTE Control Center (GCC)
Support for Q-Flash
Support for Q-Flash Plus
Support Smart Backup
Features

These are the technical specifications.

These are the technical specifications.

These are the technical specifications.




Items Included

  • Gigabyte X870E AORUS ELITE WIFI7 AM5 ATX Motherboard

  • Limited 5-Year Manufacturer Warranty
